QY-F5190-Rack
The QY-F5000 series Industrial Monitor provides a variety of sizes from 7 to 32 inches, supports square screen and widescreen display, and meets the needs of different industries and applications. It adopts industrial-grade capacitive and resistive touch modules to provide a smooth touch experience. The all-aluminum mold middle frame and front panel IP65 design ensure the firmness and durability of the product and can withstand the invasion of harsh environments. In terms of installation, it supports embedded and VESA installation methods, which facilitates users to make a variety of installation options. DC power supply ensures low power consumption and stability of the product.
Rack-mount installation supports: 17-inch, 19-inch. Other sizes can be customized, please discuss with the salesperson for details.
PRODUCTS FEATURES
Touch type
Capacitive or Resisitive touch
Resolution
1280x1024
Display ports
HDMI+VGA/VGA+DVI
Touch ports
USB or RS-232 touch port
Power input
DC 12V, 9-36V optional
Introduce
Features
Specification
Dimensions
Introduce:
19.0 inch Industrial Monitor-Rack
1. Support VGA/DVI/HDMI multiple signal input, optional resistive/capacitive touch screen
2. Support COM and USB touch interfaces
4. Ultra-thin design, saves cabinet space, resistant to shock and vibration
5. Solid power terminal, DC 12V input, meets industrial field applications
6. Rack-mount installation to meet the needs of industry customers
7. The OSD film control button on the rear panel helps users adjust the LCD screen to the best use state
2. Support COM and USB touch interfaces
4. Ultra-thin design, saves cabinet space, resistant to shock and vibration
5. Solid power terminal, DC 12V input, meets industrial field applications
6. Rack-mount installation to meet the needs of industry customers
7. The OSD film control button on the rear panel helps users adjust the LCD screen to the best use state
Features:
Size
19.0 inch TFT LED,4:3 screen
Resolution
1280*1024
Display ports
HDMI+VGA, VGA+DVI
Touch type
Capacitive touch, Resisitive touch, Non-touch
Power input
DC 12V, 9-36V optional
Installation
Embedded installation/wall mounting/VESA installation/desktop installation
Brightness
Standard 350 cd/m², 500/1000 cd/m² optional
Operating temperature
0-60℃
Specification:
| Model | QY-F5190-Rack | |
| Display Port | HDMI+VGA VGA+DVI |
|
| Touch Port | USB (Type-B, Default) RS-232 (DB9 type) |
|
| LED Screen Size | 19.0 inch TFT LED,4:3 screen | |
| Resolution | 1280*1024 | |
| Brightness | 350 nits,support 500 / 700 / 1000 nits | |
| Largest Colorful | 16M | |
| Touch Screen Type | Capacitive | Resistive |
| Light Transmittance | More than 95% | More than 95% |
| Touch Life | 50 millions times | 35 millions times |
| Response Time | ＜5ms | ＜5ms |
| Touch Hardness | 6 Mohs | |
| Menu | Switch / Brightness + / Brightness - buttons | |
Device Information
| Power Input | DC 12V (DC 9-36V optional) |
| Working Temperature | -20℃ to 60℃ |
| Size | 435.5mm*360.5mm*57mm |
| Installation | Desktop / Embedded / Wall / Rack Mounted |
| Protection | Front panel IP65 water proof |
| Heat dissipation | Fanless Design, Conduction Heat Dissipation |
Ordering Information
| Model Name |
Display Port |
Touch Port |
Touch Screen Type |
Power Input |
| QY-F5190-Rack | HDMI+VGA | USB | Capacitive Resisitive |
DC 12V |
| RS-232 | ||||
| VGA+DVI | USB | |||
| RS-232 |
Dimensions:
