P8000 Series Industrial Panel PC
Support Win 7/ 10 / 11 and Linux system
4:3 size: 7 / 8 / 10.4 / 12.1 / 15 / 17 / 19
16:9 size: 10.1 / 13.3 / 15.6 / 17.3 / 18.5 / 21.5 / 23.8 / 27
Power input: DC 9-36V
The P8000 series of new generation industrial Panel PCs have a modular design, capacitive touch/resistive touch options, and a molded back cover. high anti-interference design and strong scalability, which can meet the requirements for use in harsh industrial environments.
It has good dustproof, heat dissipation, vibration resistance, EMC performance , high system reliability and strong environmental applicability.
The connection between the panel and the host adopts a reliable modular design and wireless relay link. Through flexible matching, it can realize the selection of multi-specification all-in-one computers and single hosts without changing the original site.
It is a product for industrial automation industry, medical informatization, and industrial field control applications
P8000 Series
| Products | Model Name | Display | CPU | I/O | Expansion |
|
QY-P8070
|
Size: 7 inch LED Screen Touch: Capacitive or Resistive Ratio: 4:3 Resolution: 800*480 Brightness: 350/1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/6/7/8/10th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/232 Power: DC 12V |
2*Mini PCIE Slots |
|
QY-P8080
|
Size: 8 inch LED Screen Touch:Capacitive or Resistive Ratio: 4:3 Resolution: 800*480 / 1024*768 Brightness: 350 / 1000 nits |
Celeron：J1900 / J6412 Atom：N95 / N100 Core: 4/6/7/8/10th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/232 Power: DC 12V |
2*Mini PCIE Slots |
|
QY-P8101
|
Size: 10.1 inch LED Screen Touch: Capacitive or Resistive Ratio: 16:10 Resolution: 1280*800 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/6/7/8/10th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/232 Power: DC 12V |
2*Mini PCIE Slots |
|
QY-P8104
|
Size: 10.4 inch LED screen Ratio：4：3 Touch: Capacitive or Resistive Resolution: 1024*768 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply:DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8121
|
Size: 12.1 inch LED screen Ratio: 4:3 Touch: Capacitive or Resistive Resolution: 1024*768 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom: N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply:DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8133
|
Size: 13.3 inch LED screen Ratio: 16:9 Touch: Capacitive or Resistive Resolution: 1920*1080 Brightness: 350 /1 000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply:DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8150
|
Size: 15 inch LED screen Ratio: 4:3 Touch: Capacitive or Resistive Resolution: 1024*768 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply:DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8156
|
Size: 15.6 inch LED screen Ratio: 16:9 Touch: Capacitive or Resistive Resolution: 1920*1080 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply:DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8170
|
Size: 17 inch LED screen Ratio: 4:3 Touch: Capacitive or Resistive Resolution: 1280*1024 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply: DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8173
|
Size: 17.3 inch LED screen Ratio: 16:9 Touch: Capacitive Resolution: 1920*1080 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply: DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8185
|
Size: 18.5 inch LED screen Ratio: 16:9 Touch: Capacitive Resolution: 1366*768 / 1920*1080 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply: DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8190
|
Size: 19 inch LED screen Ratio: 4:3 Touch: Capacitive or Resistive Resolution: 1280*1024 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply: DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8215
|
Size: 21.5 inch LED screen Ratio: 16:9 Touch: Capacitive or Resistive Resolution: 1920*1080 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom: N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply: DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8238
|
Size: 23.8 inch LED screen Ratio: 16:9 Touch: Capacitive Resolution: 1920*1080 Brightness: 350 / 1000 nits |
Celeron：J1900 /J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply: DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
|
QY-P8270
|
Size: 27 inch LED screen Touch: Capacitive Ratio: 16:9 Resolution: 1920*1080 Brightness: 350 / 1000 nits |
Celeron：J1900 / J6412 Atom：N95 / N100 Core: 4/7/8/10/11/12/13th-i3/i5/i7 |
Ethernet: 2*RJ-45 USB: 4*USB COM: 4*RS-232+2*RS-485/422/232 Display: 1*HDMI Audio: 1*Line-out Power Supply: DC 9-36V |
1*Mini PCIE Slot Support Daughter Card |
Not seeing the option you’re looking for? Have our sourcing experts assist you!
Applications
Products are widely used in military, telecommunications, metallurgy, transportation, power, railway, aviation, communications, finance, network, medical, machinery manufacturing, precision instruments and other fields.
OEM /ODM Custom
Customize your own brand industrial panel pc with confidence from here
Our core competency is the ability to customize even with small batches.
We can sign a confidentiality agreement with customers to protect the design drawings, appearance styles, functions, and logos of customized products.
The product has a 3-year warranty and permanent technical advisory services.
Certified
Ipctech adhering to the "quality Qiyang, innovation Qiyang, service Qiyang" core values, with high-quality, long-term stability of the R&D team and customer service team. The R&D team continues to develop and innovate products to meet the needs of different customers and solutions in different industry sectors.
Our products have many certificates required by different industries,such as CE,FCC,ROHS,CCC and so on.
Certified by ISO9001:2015,CE,ROHS,EN50155,EN60601,EN60945,IEC60945,etc.
Timely and effective after-sales service, 3-year warranty!
Factory research and development advantages, product quality is guaranteed.
