Industrial PC
Support 3G, 4G, Wifi, Bluetooth dual communication modules
waterproof, explosion-proof, dustproof, and capable of high-temperature operation
WINDOWS/LINUX operating system
Engineered for exceptional reliability in the most demanding environments, this product offers extensive customization options. It is available in ruggedized variants that are waterproof, explosion-proof, dustproof, and capable of high-temperature operation, ensuring unwavering performance where it matters most.
Fanless Mini Pc can be VESA mounted behind a monitor, on a wall, DIN rail, or desktop mounted. But they are engineered for industrial applications with industrial-grade components,fanless operation.
Industrial PC
| Products | Model Name | Display | CPU | I/O | Expansion |
|
QY-B5100
|
1*HDMI 1*DP |
Celeron：J1900 Core： i3,i5,i7-4/6/7/8/10th |
Ethernet:3*RJ-45 USB:4*USB COM:4*COM GPIO:8 ports GPIO Power Supply:DC 9-36V |
1*Mini PCIe Slot Support 4G and Wi-Fi |
|
QY-B5200
|
1*HDMI 1*VGA |
Celeron：J1900 Corei：3,i5,i7-6/7/8/10/12/13th |
Ethernet:2*RJ-45 USB:4*USB COM:6*COM
Power Supply:DC 9-36V
Audio:1*SPK/MIC 2 in 1 |
1*Mini PCIe Slot Support Daughter Card |
|
QY-B5300
|
1*HDMI 1*VGA |
Atom：N100/N2840 Celeron：J1900 Core： i3,i5,i7-4/5th i3,i5,i7-6/7/8/10/12/13th |
Ethernet:2*RJ-45 USB:6*USB COM:2*RS-232 Audio:1*SPK/MIC 2 in 1 Power Supply:DC 12V |
1*Mini PCIe slot |
|
QY-B5400
|
1*VGA Optional |
Celeron：J1900 Core： i5,i7-4/6/7/8/10th |
Ethernet:2*RJ-45
USB:4*USB COM:6*COM GPIO:8*GPIO (optional) Power Supply:DC 9-36V |
1*Mini PCIe slot for WIFI |
|
QY-B5600
|
1*HDMI 1*VGA |
Core：i3,i5,i7-6/7th |
Ethernet:5*RJ-45 USB:10*USB COM:8*COM GPIO:14 ports GPIO Audio:1*SPK+1*MIC Power Supply:DC 9-36V |
2*Mini PCIe slots |
|
QY-B5610
|
1*HDMI 1*VGA |
Core: i3,i5,i7-6/7th |
Ethernet:5*RJ-45
USB:10*USB COM:8*COM(12*COM optional) GPIO:14 ports GPIO Power Supply:DC 9-36V |
2*Mini PCIe slots |
|
QY-B5700
|
1*HDMI 1*VGA |
Core : i3,i5,i7-6/7/8/10th |
Ethernet:2*RJ-45
USB:8*USB COM:6*COM Audio:1*SPK+1*MIC Power Supply:DC 9-36V |
2*Mini PCIe slots |
|
QY-B5700-C
|
1*HDMI 1*VGA |
Core： i3,i5,i7-7/8/10/11/12th |
Ethernet:2*RJ-45
USB:8*USB COM:6*COM Audio:1*SPK+1*MIC Power Supply:DC 9-36V |
2*Mini PCIe slots Support Daughter Card |
|
QY-B5800
|
1*HDMI 1*VGA |
Celeron: J1900 Core: i3,i5,i7-4th |
Ethernet:2*RJ-45
USB:8*USB COM:6*COM Audio:1*SPK+1*MIC Power Supply: DC 9-36V |
2*Mini PCIe slots |
|
QY-B5900
|
2*HDMI 1*DP |
Core: 8 / 9th-i3 / i5 / i7 / i9 Desktop CPU |
Ethernet: 2*LAN USB: 4*USB COM: 2*RS-232 / 422 / 485 (DB9 type) + 2*RS-232 (DB9 type)
Audio: 1*Line-In+1*Line-OutDisplay: 2*HDMI+1*DP Power input: DC 9-36V |
2*M.2 Slots, Support 4G and WIFI module |
|
QY-B6000
|
1*HDMI 1*DVI 1*DP |
Celeron G series Core: i3,i5,i7-4/6/7/8/9th Desktop CPU |
Ethernet:2*LAN
4*LAN/6*LAN(optional) USB:8*USB COM:6*COM 8*COM/10*COM(optional) Audio:1*SPK+1*MIC Power Supply:DC 9-36V |
1*Mini PCIe slot 1*PCIE 16x,1*PCIE 1x 2*PCI slots(optional) |
|
QY-B6100
|
1*HDMI 1*DVI 1*DP |
Celeron G Series/Pentium Gold Series Core:12/13/14th-i3/i5/i7/i9 |
Ethernet:2*LAN
4*LAN/6*LAN(optional) USB:8*USB COM:6*COM 8*COM/10*COM(optional) Audio:1*SPK+1*MIC Power Supply:DC 9-36V |
1*Mini PCIe slot 1*PCIE 16x,1*PCIE 1x 2*PCI slots(optional) |
|
QY-B7100
|
1*HDMI 1*DVI 1*DP |
Celeron G series Core: i3,i5,i7-4/6/7/8/9th Desktop CPU |
Ethernet:2*LAN
4*LAN/6*LAN(optional) USB:8*USB COM:6*COM 8*COM/10*COM(optional) Audio:1*SPK+1*MIC Power Supply:DC 9-36V |
1*Mini PCIe slot Support 4G and Wi-Fi 1*PCIE 16x,1*PCIE 1x 2*PCI slots(optional) |
|
QY-B8000
|
1*HDMI |
Celeron：J1900/j6412/
Core： i3,i5,i7-4/6/7/8/10th |
Ethernet:2*RJ-45
USB:4*USB COM:6*COM Audio:1*SPK/1*MIC 2 in 1 Power Supply:DC 9-36V |
1*Mini PCIe slot Support Daughter Card |
|
QY-B8000-DC
|
1*HDMI |
Celeron G Series
Pentium G Series
Core: 6 / 7 / 8 / 9th-i3 / i5 / i7 / i9
|
Ethernet:2*RJ-45
USB:4*USB COM:6*COM Audio:1*SPK/1*MIC 2 in 1 Power Supply:DC 9-36V |
1*Mini PCIe slot 1*Expansion Card Slot |
Not seeing the option you’re looking for? Have our sourcing experts assist you!
OEM /ODM Custom
Customize your own brand with confidence from here
Our core competency is the ability to customize even with small batches. We can sign a confidentiality agreement with customers to protect the design drawings, appearance styles, functions, and logos of customized products. The product has a 3-year warranty and permanent technical advisory services.
Industry Certificates
Our products have many certificates required by different industries, such as CE, FCC, ROHS, CCC and so on. EN50155 for rail transit, EN60601 for medical equipments, EN60945 for navigation computers/marine computers in Europe, IEC60945 for navigation computers/marine computers in North America and so on.
FAQ
How to dissipate heat ?
A: Intelligent Fan Cooling Structure ,Fanless cooling design Born to cope with harsher environments, not afraid of challenges
The whole machine is made of all-aluminum alloy body, and the intelligent fancooling structure design has low noise, high and low temperature resistance,dustproof and moistureproof, and can effectively deal with harsh environments
Is High-speedconnector ?
A: High-speed connector:fast signal transmission and more stable performance
High-speed interface, through which the wireless connection between the main boardand the daughter cards with different I/O functions is realized, providing a large numberof additional functions for the product, such as USB, COM, Gigabit Ethernet ports andother interfaces;To better meet the customer's program needs.
Can you put my brand name (logo) on these products or provide customized solutions?
A: Yes, we can support OEM/ODM service, the process of customization is following:
* Provide your specific requirement.
* Our engineer draws the design draft.
* You confirm the design draft.
* We start produce it.
Are you a factory or trading company?
A: We are a professional consumer electronics manufacturer which located in Zhengzhou, China.
If we come to China, can you arrange the visiting to your factory?
A: We warmly welcome and look forward to your visiting to our factory at any time.
